Funkbeschicker FB 11

This unit functions as a correcting interface between the DF-loop-system and the (slave) navigation-compass. The miss-reading due to the shape of the fuselage of an aircraft is being compensated by means of a so-called curved plate.

The photograph is self-emplaning

The moving arm on the right-hand side, is linked with the repeater potentionmeter (also known as "dynasyn")
